Medidas e pesos orientativos
Espessura (BWG)	Espessura (mm)	Comprimento (mm)	Largura (mm)	Peso (kg/m²)	Peso (kg/pç)
30	0.3	1200	600	2.55	1.836
30	0.3	2000	1000	2.55	5.1
28	0.35	1200	600	2.975	2.142
28	0.35	2000	1000	2.975	5.95
27	0.41	1200	600	3.485	2.509
27	0.41	2000	1000	3.485	6.97
26	0.46	1200	600	3.91	2.815
26	0.46	2000	1000	3.91	7.82
25	0.51	1200	600	4.335	3.121
25	0.51	2000	1000	4.335	8.67
24	0.56	1200	600	4.76	3.427
24	0.56	2000	1000	4.76	9.52
23	0.64	1200	600	5.44	3.917
23	0.64	2000	1000	5.44	10.88
22	0.71	1200	600	6.035	4.345
22	0.71	2000	1000	6.035	12.07
21	0.81	1200	600	6.885	4.957
21	0.81	2000	1000	6.885	13.77
20	0.89	1200	600	7.565	5.447
20	0.89	2000	1000	7.565	15.13
19	1.07	1200	600	9.095	6.548
19	1.07	2000	1000	9.095	18.19
18	1.24	1200	600	10.54	7.589
18	1.24	2000	1000	10.54	21.08
17	1.47	1200	600	12.495	8.996
17	1.47	2000	1000	12.495	24.99
16	1.65	1200	600	14.025	10.098
16	1.65	2000	1000	14.025	28.05
15	1.83	1200	600	15.555	11.2
15	1.83	2000	1000	15.555	31.11
14	2.11	1200	600	17.935	12.913
14	2.11	2000	1000	17.935	35.87
13	2.41	1200	600	20.485	14.749
13	2.41	2000	1000	20.485	40.97
12	2.77	1200	600	23.545	16.952
12	2.77	2000	1000	23.545	47.09
11	3.05	1200	600	25.925	18.666
11	3.05	2000	1000	25.925	51.85
	3.17	1200	600	26.945	19.4
	3.17	2000	1000	26.945	53.89
	3.97	1200	600	33.745	24.296
	3.97	2000	1000	33.745	67.49
	4.76	1200	600	40.46	29.131
	4.76	2000	1000	40.46	80.92
	6.35	1200	600	53.975	38.862
	6.35	2000	1000	53.975	107.95
	7.94	1200	600	67.49	48.593
	7.94	2000	1000	67.49	134.98
	9.52	1200	600	80.92	58.262
	9.52	2000	1000	80.92	161.84
	12.7	1200	600	107.95	77.724
	12.7	2000	1000	107.95	215.9
	15.87	1200	600	134.895	97.124
	15.87	2000	1000	134.895	269.79
	19.05	1200	600	161.925	116.586
	19.05	2000	1000	161.925	323.85
	22.22	1200	600	188.87	135.986
	22.22	2000	1000	188.87	377.74
	25.4	1200	600	215.9	155.448
	25.4	2000	1000	215.9	431.8

Chapa Latão

Latão

Chapa Lisa Latão

Tabela de medida Chapa Lisa Latão
